How to Use:

Turn On the unit, change desired temperature unit if ^oC or ^oF, data log in time units and put inside the incubator. Allow maximum of 10 minutes to take this unit in stable reading of your incubator temperature and humidity

Compare the reading if within egg incubator parameter.

Laminated colored print out is supplied upon buying this humidity tester.

See  attached picture – How to Check Humidity and Corrective Action.

Function:

• Humidity Meter

• Temperature Meter

• Wet Bulb Temperature

• Dew Point Temperature

 Features:

• dual display of humidity and temperature reading

• digital reading, fast and accurate measurement

• quick response time, comes with a sensitive humidity / semiconductor sensor

• high accuracy and performance by providing useful measurements for analysis of hatching egg incubator condition

• combined function of humidity, temperature, wet bulb and dew point temperature.

• maximum and minimum data hold function

• LCD display with backlight and auto power off after approximately 15 minutes with disable function

 Operating Range:

• Humidity: 0 ~ 100% Relative Humidity

• Temperature: – 30 ^oC ~ 100 ^oC (-22F ~ 199F)

• Dew point Temperature: -30 ^oC ~ 100 ^oC (-22 ^oF ~ 199 ^oF)

• Wet Bulb Temperature: 0 ^oC ~ 80 ^oC  (32 ^oF ~176 ^oF)

Accuracy And Response Time:

• Humidity Accuracy: +/- 2%RH (at 25 ^oC, 20% ~ 80%R.H.) & +/- 2.5%R.H. (at other ranges)

• Air Temperature Accuracy: +/- 0.5 ^oC / 0.9 ^oF (at 25 ^oC) & +/- 0.8 ^oC /1.5 ^oF (at all ranges)

• Resolution: 0.01%R.H, 0.01 ^oC / 0.01 ^oF

• Response Time: %RH:10s (90% at + 25 ^oC still air)

 Limitation:

• Operating Temperature: 32 ^oF to 104 ^oF (0 ^oC to 40 ^oC); <80%RH

• Storage Temperature: 14 ^oF to 140 ^oF (-10 ^oC to 60 ^oC); <80%RH

Physical:

• Product Weight: 150g

• Package Weight: 250g

• LCD Display: 36 x 40mm

• Product Size: 225 x 55 x 32mm

• Package Size (L x W x H): 296 x 145 x 60mm

 Certification:

• Approved: CE / FCC

• EPC_INS_302

 Product Warranty

• After Sales Service: 1 Year Warranty

 Accessories:

• Instruction User Manual

• 1 PC Black Bag

• Laminated Print Out of Incubator Temperature And Humidity Parameters
